FTTH Drop Cable Production: Manufacturing Process Explained
Surprising fact: over seventy percent of new U.S. broadband builds now rely on fiber networks that require tight manufacturing control to hit performance targets.
Shanghai Weiye OFC Equipment manages end-to-end fiber secondary coating line manufacturing, from sourcing brand fibers like Fujikura or Corning® SMF-28e to comprehensive test documentation that ensure 100% quality assurance.
Our drop designs suit aerial, underground, and direct burial installation, with LSZH, polyvinyl chloride (PVC), and polyethylene (PE) jacket options and core counts from 1 to 4 cores. We supply OS1/OS2 and OM2–OM4 grades plus ITU-T G.652D and G.657 variants, Pantone-matched sheath colors, and logo printing.
Automation and precision equipment stabilize line speed and repeatability high. Typical lead times are 4–5 days for orders < 100 km and 7–10 days for < 500 km, with an min. order of 1 km and warranty for free replacement on quality issues.
Keep reading to understand how materials, testing, and support combine to lower lifecycle cost and match the right product to your network system.
- Shanghai Weiye OFC Equipment delivers end-to-end manufacturing and lab testing for U.S. deployments.
- A range of jacket options and optical grades cover varied installation environments.
- Automated production lines deliver stable quality and reliable optical performance.
- Quick lead times, low MOQ, and recognized brand fibers support reliable procurement planning.
- Comprehensive test reports and after-sales warranty back product reliability and documentation needs.
FTTH Manufacturing Expertise by Shanghai Weiye OFC Equipment
When project timelines and performance matter, Shanghai Weiye OFC Equipment provides customized drop cables with full test documentation.
As a focused supplier and manufacturer, Shanghai Weiye OFC Equipment pairs purpose-built equipment with tight material control. We provide custom builds and services for residential/MDU deployments. Every order comes with 100% quality assurance and full test reports.
Our lab performs high-temperature, salt spray, and vibration testing to validate durability. Jacket options cover LSZH, PVC, and PE. Designs cover bow-type flat and figure-8/self-supporting styles and use brand fibers such as Fujikura® and Corning SMF-28e.
- Documented line control and production checks for fully auditable shipments.
- Engineering support for requirements, pilots, and scaling.
- Modern fixtures and calibration reduce variability so every cable matches operator specs.
FTTH cable production
At Shanghai Weiye OFC Equipment, manufacturing steps are aligned to network specifications, pairing brand fiber choices with disciplined test flows.
Optical fiber selection and brand options
We select fiber draw tower to minimum bend radius, loss, and install environment. Options include OS1, OS2, OM2–OM4 and ITU-T G.652D, G.657.A1/A2. Brand fibers such as Fujikura and Corning® SMF-28e are offered to satisfy sourcing standards.
Integrating Strength Members
Strength members use dielectric FRP or metallic steel wire. FRP is preferred where non-conductivity is necessary. Steel wire adds tensile strength for longer aerial spans and bonding/grounding needs.
Jacket Options and Control
Jacket options include LSZH for flame/smoke safety, PVC for flexibility, and PE for UV/moisture resistance outdoors. Tight process control of extruder temperature and capstan speed keeps line speed stable and dimensional tolerances.
| Component | FRP | Metallic Steel |
|---|---|---|
| Primary use | Non-conductive runs | High-tension aerial runs |
| Key benefit | Light, non-corrosive | High strength |
| Installer note | Easier terminations | Bonding/grounding required |
Inline and final testing
Inline geometry and concentricity checks run during manufacturing. Final optical tests confirm attenuation and reflectance. Each order includes a 100% test report and lab results from high-temperature, salt fog, and vibration trials to confirm handling for drop terminations and field use.
Typical lead times are 4–5 days for < 100 km and under 500 km in 7–10 days. Lot records and first-article approvals provide traceability and compliance for U.S. projects.
Our FTTH Drop Cable Types and Structures
Shanghai Weiye OFC Equipment offers a focused portfolio of drop designs that suit both tight indoor routes and exposed aerial spans. Each option combines tested materials with field-termination geometry and consistent optical performance.
The bow-type flat drop cable minimizes footprint for risers and conduit. It keeps bend loss low for easy routing in MDU corridors and hallways.
Self-supporting designs for aerial spans
Self-supporting FTTH drop designs use a messenger element to carry tensile loads. Choose dielectric FRP for electrical isolation or steel wire when bonding/grounding and extra tensile strength are required.
Layouts & Strength Members
We offer both dielectric and metallic strength member configurations to match safety and EMI rules. Central loose-tube and flat unitube types balance crush resistance and fiber ribbone line for fast terminations.
Jackets for Indoor/Outdoor
Jacket choices include LSZH for indoor flame/smoke compliance and PE for outdoor UV and moisture resilience. Each series is validated for mechanical and optical quality before shipment.
| Type | Best use | Strength member | Sheath |
|---|---|---|---|
| Bow-type flat | Indoor risers, MDUs | FRP (dielectric) | Low-smoke zero-halogen |
| Self-supporting | Overhead spans | Steel wire or FRP | Polyethylene |
| Center loose tube | Higher fiber counts | Dielectric FRP | LSZH or PE |
| Unitube flat | Low count, quick strip | FRP/Steel | LSZH/PE |
Production Assets for Speed and Quality
Automation with sensor feedback at Shanghai Weiye OFC Equipment cut manual handling and increase throughput for drop patch preparation.
Our production line uses automated machines that cut/strip drop cords to increase output and cut labor variability.
The CLX-BPO2 automated stripper runs under PLC and photoelectric control. One cycle is ~1.5 s, giving real-world speeds near 20 terminal operations per minute.
Automated cutting and stripping for drop cable patch cords
The equipment strips LSZH/PVC jackets and trims FRP/steel members to precise reserved lengths. Cylinder-driven actuators deliver fast, repeatable motion and minimize downtime.
PLC/photoelectric control for precision and repeatability
PLC logic + photoelectric sensors deliver precise positioning and closed-loop control. Inline checks update SPC charts so operators can correct trends before defects grow.
| Item | Spec | Result |
|---|---|---|
| Machine | Auto-strip, ~1.5 s cycle | ~20 terminals/minute throughput |
| Actuation | Pneumatic cylinders | High speed and reliability |
| Materials | LSZH/PVC; FRP/steel | Accurate stubs, clean terminations |
| Process control | PLC/photoelectric with in-line SPC | Stable quality, reduced rework |
- Auto scrap ejection and ergonomic loading keep the line clean.
- Process control plans capture calibration intervals and critical parameters.
- Combined machines, fixtures, and trained staff support FTTH volume targets without sacrificing accuracy.
What the CLX-BPO2 Adds
The CLX-BPO2 provides industrial-grade strip/trim to our line, cutting cycle time while maintaining consistent prep.
Shanghai Weiye OFC Equipment deploys the CLX-BPO2 to increase throughput and standardize terminal quality. The unit cycles in ~1.5 seconds, producing around 20 preps per minute in production.
PLC and photoelectric control deliver exact detection and repeatable motion. That control keeps strip and stub lengths within tight tolerances.
Line Speed
Typical operation speed is ~1.5 seconds per cycle. This translates to steady throughput under continuous line conditions.
Jacket Strip & Stub Lengths
The CLX-BPO2 handles LSZH/PVC with an adjustable jacket strip length from 17.5 to 35.0 mm. Reserved strength member stubs are adjustable from 7.0–11.0 mm to match common termination hardware.
Cutting FRP/Steel Members
The machine cleanly cuts FRP and steel wire strength elements while protecting neighboring fibers. Customized cutters are available for non-standard cross-sections to maintain precision.
- Auto-eject scrap and sensor-triggered start reduce idle time.
- Compact size (L40 × W18 × H18 cm), 110–220V, 50W, and 11 kg mass simplify cell integration.
- Cylinder-driven motion and PLC/photoelectric control boost reliability and reduce maintenance downtime.
| Specification | Rating | Why it matters |
|---|---|---|
| Cycle | ~1.5 s (~20/min) | High throughput for production runs |
| Strip lengths (A) | 17.5 to 35.0 mm | Compatible with common connectors |
| Reserved stub (B) | 7.0 to 11.0 mm | Meets strength and termination needs |
| Power/Size | 110–220V, 50W; 40×18×18 cm | Simple integration |
Using this machine, Shanghai Weiye OFC Equipment standardizes terminal prep so field teams get drop parts install-ready. The CLX-BPO2 supports our lines in meeting volume targets without compromising quality.
Custom Specs for Your FTTH System
Shanghai Weiye OFC Equipment configures every order to meet your network requirements and simplify deployment. We combine focused options with predictable schedules so your teams receive ready-to-install products.
Choose 1–4 core designs with single-mode or multimode fiber. Options include OS1, OS2, and OM2–OM4 along with G.652D and G.657 variants to match your optics and connector plans.
We match sheath colors to Pantone codes for quick field identification and consistent asset tagging.
Branding and Print Options
Select LSZH/PVC/PE jackets based on route and safety rules. Custom print legends and logos support inventory and warranty tracking.
Put-Ups, Packaging, and Structures
Standard put-ups are 1 km, 2 km, and 4 km with tailored reels and packaging to fit storage/handling. Choose flat bow-type or self-supporting and steel wire or FRP strength members to fit span and isolation requirements.
| Choice | Typical | Advantage |
|---|---|---|
| Reel length | 1 / 2 / 4 km | Less staging, easier reels |
| Jacket | LSZH / PE / PVC | Indoor/Outdoor fit |
| Structure | Bow-type / Self-supporting | Flexible routing/span |
As a supplier, Shanghai Weiye aligns runs to your schedule and provides docs that detail final specs for easy on-site QA.
Quality, Test, and Docs
Shanghai Weiye OFC Equipment embeds quality checkpoints across the production line so every item has recorded acceptance data at ship.
Lab Testing: Heat, Salt Spray & Vibration
Our lab conducts high-temperature exposure, salt fog corrosion, and vibration tests to qualify materials and assemblies. These tests simulate field stresses for indoor/outdoor applications.
100% test reports for every cable
Every fiber optic cable includes a 100% test report that logs attenuation, return loss, and geometry where applicable. Final inspection gates stop nonconforming items before they leave the factory.
Traceability and compliance
Lot/batch records tie test data to reels and serials so audits and claims are easy to verify. Documentation follows common customer templates to speed approvals and inbound inspection.
- Line checks and final inspection prevent field failures and lower warranty events.
- Quality packages include specifications confirmation and formatted data for quick review.
- Ongoing trend analysis drive preventive maintenance and improve long-term reliability.
| Trial | Purpose | Result |
|---|---|---|
| High-temperature | Material stability | Pass at target temperature |
| Salt-fog | Corrosion robustness | Outdoor suitability |
| Mechanical vibration | Resistance to vibration | Reduced field failures |
FTTH Drop Cable Pricing & Cost Drivers
Budgeting for a drop run begins with fiber/jacket selection and is refined by volume and customization.
Typical prices vary widely—from about $30–$1,000 per unit—based on fiber grade (G.652/G.657/OM2–OM4), jacket chemistry (LSZH, PVC, PE), reel length, and structural design.
Material choices, fiber grade, jacket type, and structure
The primary cost drivers are fiber optic grade, sheath material, and the chosen structure for deployment.
Self-supporting designs and steel strength elements raise material and labor input. Custom sheath colors/logos/legends add setup and influence price for short runs.
How Volume & Options Affect Cost
Longer reels and higher volume orders reduce unit cost. Small quantities often include setup charges and higher unit prices.
- Line changeovers and custom tooling increase lead time and add cost.
- Clear RFQs with schedule alignment let Shanghai Weiye OFC Equipment align price quotes to delivery windows.
- Framework agreements and indexed pricing stabilize budgets over phases.
| Factor | Effect on price | Guidance |
|---|---|---|
| Optical grade | High impact | Balance spec vs. budget |
| Jacket type | Medium | Evaluate LSZH vs PE |
| Length/Volume | High impact | Consolidate runs to cut unit cost |
Logistics for the U.S.
Shanghai Weiye OFC Equipment keeps lead times/logistics clear so planners can align crews and sites. Predictable windows reduce downtime and control costs when a rollout is underway.
Scheduling & Capacity Planning
Typical production windows run 4–5 days for orders under 100 km and 7–10 days for orders under 500 km. We schedule line capacity to match your rollout milestones and to maintain on-time delivery.
The service team provides updates/tracking so installation teams know when reels arrive. For compressed schedules, we hold contingency capacity to pull in critical-path orders.
Minimum order quantity and why it matters
The MOQ is 1 km. This reflects setup needs such as wire/die adjustments that consume start-up material and scrap.
We review your put-ups and staging to select reels to reduce waste/handling. Staggered batches can balance inventory holding with more frequent small-site deliveries.
Installation readiness and application scenarios
On-site conditions determine whether a self-supporting aerial, ducted pull, or direct-buried run is the right choice for a project.
Aerial, duct, and direct-buried deployment considerations
For aerial runs, Shanghai Weiye OFC Equipment recommends self-supporting designs with appropriate members to control sag and tension for long-term reliability.
Duct installations work best with low-friction sheaths and crush-resistant constructs so pulling does not damage fibers. PE jackets are common for underground and buried paths where moisture resistance is needed.
Direct-buried designs require proper depth control per local codes and moisture-resistant jackets to protect the fiber core long-term.
Indoor Riser/Plenum & ONT
Indoor riser/plenum routes prefer LSZH to meet smoke/flame codes. Flat drop profiles strip cleanly and present controlled stubs for quick ONT termination.
We guide the choice of steel or FRP (dielectric) strength members based on bonding needs, lightning risk, and hardware fit. Standardized line prep shortens install time and reduces scrap.
| Deployment | Key design | Installer note |
|---|---|---|
| Aerial | Self-supporting, steel or FRP | Verify messenger hardware/tension |
| Duct | Low-friction jacket, crush resistance | Use pull tape and proper lubricant |
| Direct-buried | PE with moisture barrier | Follow depth/warning tape codes |
| Interior | LSZH with tight-bend support | Maintain bend radius at penetrations |
Our approach delivers a consistent installation across indoor outdoor transitions. That reduces callbacks, speeds activations, and reliable field performance for your system.
End-to-end support and after-sales service
Our team coordinates testing, scheduling, and installation guidance to avoid surprises in deployment.
Shanghai Weiye OFC Equipment offers engineering support from early requirements through approved drawings and pre-production builds. We provide doc templates and clear installation notes so field crews work from the same plan.
After-sales service includes fast response, RCA, and corrective action. All products ship with full test reports and traceability to help QA acceptance.
- Round-the-clock availability for status and technical support.
- Warranty includes free replacement for confirmed quality issues.
- Coordination of line schedules for expedites and urgent changes.
- Config control so shipped items match agreed specs consistently.
| Support area | Scope | Benefit |
|---|---|---|
| Tech/Eng | Spec review & pre-production builds | Reduced field issues |
| QA/Testing | Lab + 100% reports | Full traceability |
| Service | Rapid replacement & root-cause | Lower downtime |
Wrap-Up
Select Shanghai Weiye OFC Equipment for custom drops, quick lead times, and full traceability.
We deliver customized FTTH drop solutions that combine materials with validated manufacturing and lab tests. Every reel ships with a 100% test report and documented trials to support U.S. field acceptance.
A robust production line, including CLX-BPO2-enabled prep machines, cuts variability and shortens turnaround. Our equipment set standardize strip/stub lengths so installers see consistent results at turn-up.
From fiber selection through jacket, printing, and packaging, we balance performance and cost to maximize service life. Dedicated support guides scheduling, logistics, and after-sales care so your deployment remains on plan.
Get in touch with Shanghai Weiye OFC Equipment to align specs, timeline, and volume. We stand behind every shipment with lab validation and responsive service.
